For Sale

This page is purely to assist Members of HOA, Hillyard owners and prospective Hillyard owners. Any purchaser must contact the vendor direct.

  Lady Corinne 12 TonHatite 11-Ton Chloe II 4-Ton Bonnie 9-ton Timboline 12 Ton Trooper 9 Ton    Lady Ailsa 9 Ton Cutter  Fiordingly 12 Ton Mynute 2½ Ton EVA Life Raft Neon Tetra 16 Ton Spartina 6 Ton Seabrine 5 Ton Gagawan 5.5 Ton Janet 2.5 Ton Margo 11 Ton Piccola 9 Ton   Minuet  Winsome 4 1/2 Ton

 Crusader of Arun - 12 Ton Ketch

Hillyard 12 ton Ketch, built in 1971
37’ LOA +3’bowsprit. 33’LWL. 10’beam. 4’9” draft
Flared bow, canoe stern, long keel, centre cockpit with canvas hood, round bilged
Carvel construction mahogany planking on oak timbers, copper fastened. Cast iron keel.  Internal lead ballast. Plywood fibreglass sheathed decks.
2003 BMC Commander replaced by reconditioned 64 HP Yanmar which gives comfortable cruising speed of 6 – 7 knots.  Morse control. 60 Gallons fuel capacity.  Tachometer.  2 sets 12 volt batteries. Auto battery charger.
Zodiac Cadet dinghy  2003, Plastimo 4 man liferaft last serviced 2009
Ketch rig with stainless standing rigging and terylene running rigging. Traditional roller reefing on boom.  Masts (new 2003) mounted in tabernacles. New tabernacle for main 2009   2 halyard winches. Two sheet winches new 2003. EO8 Rotostay and new reefing headsail 2000. New Mizzen 2010, Booming out pole. Beaching Legs
Ray Marine Radar, Garmin GPS
Garmin 500 series Chart plotter (brilliant in fog at L’Aber wrac’h)
Pinta autopilot   Barometer   Autohelm wind and speed &direction
B&G depth and repeater, Sailor RT144 VHF, Sestrel handbearing  Compass
Clock  curtains, cushions, cutlery etc. Calor 2 Burner cooker, grill and oven (new 2009)
2008,  Garboard planks recaulked and old Blake aft  toilet cock replaced and
New Jabsco  twist’n lock toilets fitted in aft and fore cabins.  She doesn’t leak.  Gas water heater Bottled gas in self draining locker (3 Canisters)
60 Gallons freshwater capacity Electric galley fan
SL manual anchor windlass with 2 CQR type anchors and 50 metres of chain
Wheel steering connected by cable   Boarding ladder   Fenders  Navigation lights
Radar reflector  Electric bilge pump  Stainless steel pulpit, pushpit and stanchions.  Warps Foghorns  2 lifebuoys etc  Mains electricity with lights in all three cabins
Crusader of Arun had a £20,000 refit in 1997 at Hillyards   She is on a good berth at Cherbourg, port-side to, approx £2,000 a year, including electricity, water WIFI and free showers   There are  some five English boats on the same pontoon – we keep an eye out for each other.  She is ‘My little place in France’ in a delightful port open at all states of the tide and with good sailing both East to Honfleur and West to Brest and beyond..   I sail single handed and as a ketch, with a reliable powerful engine  is easy to handle. Strong winds?  I just take down the main.  I filled her with diesel in Guernsey and she’s ready to go.
Price    £25,000.
nimc@talktalk.net

Fiordiligy - 12 Ton Sloop



Having owned and loved Fiordiligy for over 10 years, present circumstances regretfully dictate that I need to find a new caring owner. Built in 1967, Fio is in excellent fettle and is fully kitted out for long distance comfortable cruising, with all necessary safety and navigation equipment, EPIRB, liferaft, gps, radar etc. Vital statistics: Length 37 ft., Beam 11 ft. Draught 1.5 metres.
This year’s summer trip took her from Milford Haven up the West coast of Wales, England and Scotland as far as Tobermory, then South via Islay down the East coast of Ireland and back across the Irish Sea, to her summer mooring in Dale, Milford Haven. From the 1st October she will be in her winter berth at Milford Marina.
An opportunity to own an excellent example of a 12 tonner for £25000 or near sensible offer.

Contact Details: Ed Wilson Tel: 01545 560959, Mob: 07896 333569

    Email: Edward.wilson220@btinternet.com

Lilani - 6 ton no 439

Great opportunity to aquire a newly restored centre cockpit six tonner link to full details below together with points of contact for further information.

Full Details - PDF File

Bucklers Hard Boat Builders Ltd

The Agamemnon Boat Yard

Bucklers Hard

Beaulieu

SO42 7XB

Tel: 01590 616214

Primary contacts

Chris Clayton:    chrisclayton@bucklers.co.uk

Dave Blachford: daveblachford@bucklers.co.uk

Aquila

Wooden Sailing Yacht

Design/shipyard; David Hillyard, Littlehampton

Material; Larch on oak, mahagony cabin

Build; 1936

Motor: Yanmar 1GM10

Length; 22', bowsprit included 26'

Beam; 7.2'

Length mast; 30'

Price; € 12000,--

Cor van der Linde

tel. 0031235288291

cvanderlinde@kpnplanet.nl

Maid Jaqueline

I would like to politely ask, if you can include my 12 Tons
Sloop Maid Jaqueline in the Hillyard sale offers.

Under www.maid-jaqueline.de the boat is described in the
english an german language.

I am at your disposal with further informations.
With kind regards

Heinrich Radermacher
Petrusstraße 22
53 639 Königswinter

Tel.: ++49 2244-87 07 09
Fax: ++49 2244-87 01 69
Mail: heinrichradermacher@t-online.de

'Spray'

 I currently own Spray, which I believe was the first motor launch built by Hillyard in 1925, so something of a key boat in the Hillyard story..   It appears to have been commissioned for naval use during WWII.
It is now unused and ashore [near Plymouth] and I am keen to sell it, not least to avoid an historic boat falling beyond repair.
Spray is a 30’ launch with 2 berths and cockpit space for about 10.  It was in commission until last year, and the engine [now a Nanni diesel] was substantially rebuilt just 4-5 years ago.   However the exterior needs tlc – the deck needs some resealing, there are probably a couple of planks to replace and brightwork needs revarnishing.   It needs some time by a person with basic boat maintenance skills to bring it back to sound use but I’m not aware that there is anything substantially wrong.
I wonder if, through your association networks, you could alert anyone who may be interested in viewing Spray with a view to buying at a realistic ‘quick sale’ price.
Some recent photos are attached for information.
Prospective purchasers should phone Scott Brown at 01752 851679 or email him at info@boatingworldsw.co.uk

John Forster

"Anne" - 4 Ton

Hello all Hillyard - enthusiasts
Next to my Vertue in Kampen (Netherlands) there is a very nice and clean 4-to Hillyard "Anne" ( 6,50 x 2,20 x 1,10 m) to be seen and for sale. She is afloat, but in need of painting and caulking. She is empty, her joinery had been taken out, but is to 75 % existing and could easily be reinstalled. Her plankwork is pitchpine and is sound. From the inside she is very clean.

There is a 7 hp 2-stroke Vire engin to be installed. "Anne" has a nice good teakdeck and mahogany- superstructure.
She is  gaff rigged with bouwsprit and as-new sails. Mast, gaff and gig varnished and in good order, also all her rigging. The hatches are as new. There is some work to be done to the small deep cockpit, i.e. the cockpit sole.
All together: after the words of the head Mr. Bakker of the renowned "Kroes" boatyard, where "Anne" is moored, during winter ashore under cover, "Anne" is absolutely sound, but needs some reconditioning.
"Anne" is owned by the Kroes- yard. They ask 3000 Euro, which means about 2.600 British pounds or maybe a bit less, a bargain indeed.
Please contact Mr. Bakker (www.kroesbootbouwers.nl , there you will see the advertisement under "te koop" together with 3 fotos of "Anne"). His mail address: kroesbootbouwers@gmail.com, his telephone number: 0031 383312684
Greetings from
Rudolf Grimm

Nourlangie

16 ton Hillyard ketch
Iroko on Oak frames
6 Cylinder Perkins Diesel Engine
Extensively restored over recent years
Overhauled Engine
Rewired with three new batteries
New hot water and webasto central heating system installed
Well Equiped for long distance cruising
2009 Survey
Some completion work required ie internal wooden fitttings
Afloat Littlehampton
£25,000
hillyardyachts@ntlworld.com

Icon (ex Gilaroo 1953 Build No.488) 9 Ton

The boat is located just behind a little cafe adjacent to a pub (name not to hand) -on the hard between cafe and river.
Images below

 Lady Corinne -12 Ton

For Sale - Our cherished 1939 12 Ton Hilyard Ketch "Lady Corinne"

A beautiful 45 foot overall double ended, carvel planked hull with
Pitch Pine planking on Oak Frames she was started in Littlehampton  in
1939 and the hull was completed before the yard turned its attention
to the war effort.  During the next few years she lay in a mud berth
where the salt water preserved her timbers until she was finished and
commissioned in 1945 She was the first boat to leave the Hilyard yard
after the war.
She has had a colourful life including many years as an RAF training
ship after being bought to replace one of the windfall yachts gained
from the Luftwaffe which was dashed on the rocks somewhere off the
French coast.  We returned to Chichester last year after a 16 day
Transatlantic crossing from the Cape Verde Islands to St Lucia in the
Caribbean after which followed an extended cruise around the Islands.
The final chapter saw us enter her for the Antigua Classics in 2010
where we achieved 2nd in class and second place in the Privately
Maintained Concours de Elegance.  In spite of her years this Lady is
still turning heads - a true beauty she really is a gem and is much
admired everywhere she goes getting praise from lots of passing boats.
 She has a ton of solid Douglas Fir for her main mast together with a
beautiful 8' Bowsprit and a short Bumpkin.




The following list is not comprehensive but is designed to give an
insight, together with the photographs, into her overall condition.

Castellated Teak Cockpit grating
Oversized Stainless Steel standing rigging and all bottle screws replaced 2005
4 x Semi- flexible Solar Panels to Coach House
2 x 145 amp hour deep cycle marine batteries for domestic -2009
1 dedicated gel battery for engine starting
X-Alt Driftgate 2000 & X-Split battery monitor & charging system
New Vetus Exhaust System including new hoses and exhaust gas temperature monitor
All Through-Hulls, Hoses and Seacocks replaced 2009
New Gas pipes and regulator
Complete suit of new sails with matching main & mizzen stack packs 2005
New inner and outer Rotostay roller furling 2005
New Lewmar Bronze two-speed self-tailing winches for outer 2005
New Lewmar Bronze Single speed winches for inner 2005
New engine monitoring instruments, Oil pressure, Water Temp & Amps 2005
Plastimo Bulkhead mounted Brass Clock & Barometer 2005
35 LB CQR Anchor with ample galvanised chain
Kedge anchor with chain & warp
Plastimo Atlantic 2 burner cooker with grill and oven
Fridge (12 Volt DC)
Shore power equipment with 13 amp sockets throughout and mains saloon lights
Folding , stowable Cockpit Table
Matching canvas covers for hatches and cockpit
Masthead LED Trilight
Mast mounted deck light
Hella navigation lights
Rule Automatic electric bilge pump 2009
Self draining cockpit 2009
Plastimo 4 man life raft
Many fastenings replaced and 16 frames replaced 2009
Wood burning stove in saloon
Icom DSC VHF 2006 with waterproof external extension speaker
Kenwood Stereo cd/radio with Aux input
4 x 150 watt Fusion waterproof speakers (2 - saloon and 2 - cockpit)
Whale Gusher manual bilge pump
Blakes manual sea toilet
Simpson Lawrence manual anchor windlass with aux gypsy
Raymarine RL70C Radar & Chartplotter 2006
Garmin GPS 152H 2011
Raymarine ST6002 autohelm including steer to wind
Raymarine ST60 Wind instrument
Raymarine ST60+ Depth
Plasitimo ships compass
Perkins 4.108 engine - completely rebuilt and painted 2007
New hurth 2:1 gearbox 2010
Kiwi folding propeller
Substantial teak deck (15mm Teak laid over new 17mm marine ply base)
Fire extinguisher and fire blanket

Lying : Itchenor Reach, Chichester Harbour, West Sussex

£50,000.00

Tel: 01243 532590
Mob: 07801 255772
e-mail : gaynormac@gmail.com

Hattie 1970 11 ton ketch

Length 33ft, built in 1970

Hattie has been a great family boat. We have sailed her down the south coast from Rye in Sussex to the Scillies. She is a very seaworthy and comfortable boat, great for exploring the coast and rivers and will cruise at 6 knots in most conditions. She has a long keel with bilge plates, drawing about 1m, which makes her very forgiving in shallow water and we have taken her up the Tamar to Calstock, regularly up to Gweek on the Helford, explored the Scillies and many other interesting places. Previous owners have taken her to Greece and in the French canals as the masts can be easily lowered and raised again on their tabernacles.

There is good headroom throughout, I am nearly 6'2" and can stand comfortably. The bunks are a good size and the separate cabins add convenience. There is great live aboard potential on this boat.

Hattie had a major refit in 2002 which included new Nanni/Kubota 62hp 5cyl diesel engine, gearbox and instruments, stainless long range fuel tank, hot water system, new keel bolts, re-galvanising of deck fittings and new sails and covers. Since then we have continued to maintain and improve her with new heads fore and aft, large fresh water tank, stainless steel cooker and stainless rigging and davits.

2009 insurance survey available.

Further details can be found on boatshed.com (http://falmouth.boatshed.com/hillyard_11_ton-boat-110316.html) and on gweek quay and ancaster websites. She is currently moored on the Helford river and winters in Gweek Quay.

Patsy Rye

4 ton, 1937, teak on oak.

£12,750
Very unusual high quality construction. Teak on oak, copper fastenings, bronze keel bolts, lead keelson. Comprehensively refitted 2005-2007, whilst the owner was a chandler – so no expense spared. Yanmar 1GM10 c1996.  Owner giving up boating after 59 years.

Detailed photo tour, and a record of 4 seasons of UK coastal and French inland cruising, can be found on the owner’s blog: njdafloat.blogspot.com

A full manifest can be seen on this pdf:  Patsy Rye Manifest

You can contact the owner by e-mail: nigel.davidson@live.com

or by phone:

hm: 01227 752860   mob: 07770 792469

Winsome 4 1/2 Ton

CHLOE II

Blink Bonnie

The current owner of Blink Bonnie writes;

I have a 9 ton Hillyard in need of restoration, I have had the boat assesed by a professional wooden boat builder and he feels the boat is well worth restoring. I have all the bits with the exception of the mast and would be willing to pass the boat on to some one who could complete the project. I have just taken a new job and have another boat so I now realise I will never be able to complete the Hillyard, which is ashore in a yard near Chichester, it seems a shame to see such a lovely boat go to ruin, so if you know of anyone looking I would be glad to here.

Joline 12 Ton


'JOLINE' was build by David Hillyard shipyard in Littlehampton, England in 1960.
The shipyard exist since 1904 and the boats were built on David Hillyard designs.
Ther are more than 600 boats who came out from this yard and a lot are still sailing
with owner annual meetings in England.
She has a long keel.
She is a centercockpit vessel.
Lenght : 36 ft
Width : 10 ft
draught : 5 ft
weight : 11 tons
VESSEL CONSTRUCTION :
Timber vessel. Traditionnal construction.
Plankings in mahogany with copper rivets in bend "limbs" in oak.
Keel in elm.
ENGINE :
BMC Commander 2.2 Diesel.
50 HP engine.
Original engine from 1960 totally renewed in 2000.
About 300 hours since 2001.
Exhaust manifold has to be changed.
1 stainless steel tank, 300 Litres (new 2001)
RIGGING :
Timber mast in oregon pine.
Construction, 4 sides glued and screwed.
Furling headsail Profurl
Stainless wires, chainplates...
SAILS :
Mainsail 3 ris ,2005, 28 m²
Genoa 35 m²
Stormsail
3 headsails for forstay
ACCOMODATION :
7 berths (3 single and 2 double).
1 front cabin with 2 superposed single berth.
Next aft to port in a large enclosed storage place where there was toilets previously.
Next aft is the saloon with 1 settee/single berth on starboard and table convertible in
double berth on port.
The galley, aft to starboard, features double sink and stove. Opposite to port is the
navigator's table with it's 'rose des vents' inlaid work.
Separate with the cockpit is the owner aft cabin with a large double berth on port and
many storage on starboard.
There is 1,80 m height in aft cabin.
Private toilets is also in the aft cabin with hand-basin and possibility to fit up a
shower.
TOILETS :
1 Blake Baby toilet.
GALLEY :
1 gas stove Force 10 with 3 burners + oven.
2 sinks.
2 foot pumps for tap water and salt water.
WATER :
2 tanks flexible for 200 Liters
2 plastic tanks rigid for 120 Liters
ELECTRICITY :
All electricals wires are new from 2001.
2 Batteries for services 6 V / 225 Amp (de 2006)
2 Batteries for starting the engine 12 V / 60 Amp , so 120 Amp (new July 2010)
Generator Honda 650 W
Invertor PowerInverter 1500 W 220 V
2 solar pannels 55W and 75W, so 130 W
1 windgenerator Kiss (very productive)
ELECTRONICS :
VHF fixe Seavoice
GPS Furuno
Combiné Tridata Autohelm (Loch – Speedo – Sondeur)
Radar Furuno 1621
SSB receiver BLU ICOM M700 with antenn tuner AT130
Automatic pilot Raymarine SmartPilot
Autoradio Pioneer JVC MP3 + speakers.
SELLERIE :
Suncovers.
Removable dodger.
ANCHORING :
Windlass manuel Simpson Lawrence
1 anchor CQR 17 kg.
1 anchor "Plate" 15 kg.
1 anchor Danforth 15 kg.
1 small "ancre à jas"
60 m chain 10mm (new from 2010)
20 m chain 12mm.
EQUIPMENT :
Plywood dinghy BB Marine 2,70 m with leeway and rudder (to rig)
Dinghy outboard 3,5 CV Tohatsu (medium condition)
Windpilote Aries.
Dessalinisator Power Survivor 5 L/H (need revision)
Stainless "portique" holding solar panels
Stainless pipe for rigid lifeline.
OBSERVATIONS :
Patrick (professionnal wooden boat carpenter) and Viviane (professionnal skipper)
own 'Joline' since 14 years (1997).
They deeply restored her during 4 years (1997-2001) in Baden, France.
The restoration has been followed by the french Affaires Maritimes. The boat has
been gauged by the french Customs.
She get a french Approbation and Homologation for 1rst Category navigation under
CEE rules in 2000 when launched.
Most of the equipements(many keel bolts, chainplates, electricity, gazoil and water
tanks, plumbery ...) has been changed during this total refit !
We are living on board since December 2000 and we left France in August 2001 with
our first son (1 year old) on board.
Then, Spain - Portugal - Marocco - Canarias Islands (birth of our 2nd son in Las
Palmas !) (haulout in La Gomera, April 2002) - Cap Vert Islands - Senegal (haulout in
Dakar, January 2003) - Brazil - French Guyana - Trinity and Tobago (haulout in
Chaguaramas, December 2005, fixed up a bowsprit) - Carribeans Islands - Venezuela
(birth of our 3rd son in Cariaco !) - Martinique - Cariaccou (haulout, Mai 2007) -
Venezuela - ABC Islands - Colombia - San Blas Islands - Panama and Panama
Canal ! - Galapagos Islands - Marquesas - Tuamotus (haulout in Apataki and 4 month
on hull restoration, August 2009) - Marquesas (3 months works for a new plywood +
teak deck) - Society Island (haulout in Raiatea, September 2010) - Kingdom of Tonga
-
Now in New Zealand !
'Joline' is for sale because we need a bigger boat with the 3 kids growing (10, 9 and 4
years old) ...
The boat is in very good state.
We have many pictures of the differents works done.
Price : 29.500 Euros

Nanouk

Zuhra 2 1/2 Ton

"Wake Of Hamble" ex "Jeanne" 4 tons

Lady Ailsa
9 Ton Cutter

Mynute 2½ Ton Gaff

This boat has been lovingly restored, under cover, in Cornwall, regrettably personal circumstances force me to sell prior to completion of the internal fit.

The external restoration has been carried out to the highest standard, with complete replacement of the wood from the Gunwales up. Inside the woodwork has been sanded and painted and some frames repaired, the interior has been fully painted. The hull is in excellent condition and was fully chaulked.

The work so far includes;

New Deck, New Rubbing Strakes, New Hatch, New Windows, New Mast, Long keel removed and shot blasted, New Gun Metal keel bolts, and a completely renovated engine refurbished and installed by Cellar Marine Ltd, Stern Tube and glands by Norris of Isleworth.

The interior includes a factory refurbished Baby Blake Toilet. All wood inside and out was sanded down to bare wood and repainted/treated by Blakes Ltd Products. Most of the original fittings have been retained, except for the rudder, which along with the stainless steel fittings, is completely new.

All that is required to finish the project is the Standing rigging, Sails, and some carpentry in the cabin, and minor electric's.

Further details and restoration photos at http://myweb.tiscali.co.uk/24fps/

Offers and other information available from john.rossetti@tiscali.co.uk (c) John Rossetti 2007

FOR SALE - EVA LIFE RAFT

The EV4 is a four person offshore valise manufactured by Eurovinil S.p.A Grosseto- Italy, purchased from new and not discharged other than at the service inspection.
The date of manufacture is June 2001; the first service was carried out in September 2005.
The raft comes complete with the explanatory handbook and a copy of the test and survey report and Re-inspection Certificate to RORC.
The general comments completed in the service report are “Raft in very good condition viewed with owner. Replacements as above”.

Neon Tetra - 16 Ton

Spartina 6 Ton Cutter 1953 Centre Cockpit

Seabrine - 5 Ton

Gagawan - 5.5 Ton

Janet - 2.5 Ton

Margo - 11 Ton - Built 1970

Located in Walton-on-the Naze Essex LOA: 10.3m (32' 6") Beam: 1.90m (9' 6") Draft: 1.m (3' 0") Construction: Iroko planks on Oak frames Accommodation: 4 Berths in 2 Cabins

This vessel had a major refit in 2000 which included new Beta Marine 50hp engine, gearbox and instruments, new stainless steel chain plates & standing rigging, Re-galvanising of deck fittings, upgrading of gas system to modern standards including new cooker, stripping and revarnishing spars (8 coats), repainting of hull & superstructure. Eberspacher heating, hot water system, new sails Parker & Kay Davits.  Hull water tight and in good condition and keels epoxy coated

She's never been in better order; ready for sea and for further extensive cruising.

Price: £34,500. Telephone 01354 680341

The 11-ton Hillyard is a very strong sea going vessel with an easy motion and will cruise at 6 knots in most conditions.  We have cruised Margo extensively and would like to see a new owner enjoy and care for her as much as we have.

---

PICCOLA - 9 Ton

Built in 1961
length 10,00 mt.
beam 2,70
draft 1,45
displacement 8000
berths 6
cabins 2
bath 1
Engine : Perkins perama 29 hp year 1994
fuel 120 lt
water 120 lt
main sail and genoa 1999 cream colour dacron
heavy genoa, foresail.
VHF SAILOR RT144
GPS
DEPTH SOUNDER
AUTOPILOT
HEATING
FRIDGE
and lots more
The price for this boat is 55000 Euros

Please contact pime@tiscali.it
Elena Pimenoff



There are a couple of Hillyards on Ebay that need new loving homes.

First up is a 9 tonner (1965).
It needs new decks and coamings, but the hull and deck beams are apparently mostly sound. She looks to be complete and original.
http://www.ebay.co.uk/itm/Hillyard-9-ton-33ft-1965-/260827575215?pt=UK_Sporting_Goods_Sailing_Boats_ET&hash=item3cba88f3af

The other one is a 1934 6 tonner, described as basically sound, but needing tlc.
http://www.ebay.co.uk/itm/hillyard-six-tonne-cutter-rigged-sloop-/170674784680?pt=UK_Sporting_Goods_Sailing_Boats_ET&hash=item27bd0289a8

Always a shame to see these fine boats looking so sad, but maybe there is someone out there who is looking for a project to take on, so if you know anyone who may be interested, then please forward them the details!
